Ocean Willie FCB fiber-reinforced calcium silicate board

$512.0 $1258.0

Jianyuan fiber-reinforced calcium silicate board is made of high-purity quartz sand and high-grade cement, combined with wood fiber-reinforced materials, providing excellent performance such as A1 level fire prevention, moisture and mold prevention, sound insulation and heat insulation. The product specifications are diverse, with a thickness of 5-15mm, suitable for indoor and outdoor fireproof partitions, ceilings, and special functional applications. Through ISO9001, ISO14001, and EU CE certification, it meets the JC/T 564-2008 standard and is widely used in commercial buildings, factories, residential areas, and public places. Jianyuan Company, as a national high-tech enterprise, is committed to the research and production of green building materials, providing high-quality building decoration materials and fire insulation system solutions to more than 50 countries around the world.

Add To Cart

Jianyuan fiber-reinforced calcium silicate board**

1. Product Overview**

FCB calcium silicate board is mainly made of high-purity quartz sand and high-grade cement, with wood fiber as the reinforcing material. It is refined through processes such as slurry forming, pressurization, and high-temperature and high-pressure steam curing.

With superior performance such as high quality, high stability, and asbestos free, FCB calcium silicate board has been exported to more than 50 countries and widely used in various engineering projects at home and abroad.

2. Product Specifications**

-* * Standard size * :
- 2440×1220mm
- 2400×1200mm
-Thickness range: 5-15mm
- * Customizable specifications**

-* * Optional surface sanding treatment**

3. Product Technical Parameters**

*Non combustibility * *: A1 level (GB8624-2006)
*Fire resistance limit * : The system can withstand fire for 1-4 hours
*Density * : ≈ 1.25 g/cm³
*Thermal conductivity * : ≤ 0.3 W/(m·K)
*Wet expansion rate * : ≤ 0.25%
*Lateral flexural strength * : ≥ 10 MPa
*Longitudinal flexural strength * : ≥ 8 MPa
*Impermeability * : 24 hours of immersion, no water droplets appear on the bottom surface
*Frost resistance * : 25 freeze-thaw cycles without delamination or damage
*Radioactive * *: Complies with Class A standards (GB6566-2010)

4. Application Fields**

1. Architectural Decoration and Structure

-Indoor moisture-proof and fireproof partition walls, ceilings*
- * External wall insulation and wall protection board*
-High traffic places (schools, shopping malls, theaters) with partition walls and ceilings*
-Places with high sound insulation requirements (conference rooms, residences, etc.)**

2. Special function applications

-Building with additional floors, movable partition walls, and sound-absorbing and sound insulation structures*
- * Impact resistant walls, low fence spacing, wall panels*
-Kitchen and bathroom areas (kitchen cabinets, hanging cabinets, door panels, exhaust hood)*

-Billboards, signs, eaves water barriers, sun visors, etc**

5. Compliance with standards**

FCB calcium silicate board meets the JC/T 564-2008 standard and outperforms the standard requirements in key indicators such as water absorption, wet expansion, and shrinkage. The company strictly implements the internal quality control system to ensure product stability and reliability.

6. Applicable places**

-* * Commercial buildings * *: Business buildings, shopping malls, hotels, entertainment venues
-Industrial buildings: factories, warehouses, workshops
-Residential Buildings: New Residential Buildings, Renovation and Decoration

-* * Public places * *: hospitals, theaters, stations, schools

7. Product Advantages**

✅ * A1 level fire protection* 🔥 * High temperature resistance*
✅ * Moisture and mold prevention* 🌫️ * Not affected by moisture*
✅ * Sound insulation and heat insulation* 🔇 * Improve living comfort*
✅ * Lightweight and high-strength* ⚖️ * Impact resistance and durability*
✅ * Convenient construction* 🔧 * Easy to cut and install*
✅ * Energy conservation and environmental protection* 🍃 * Asbestos free, healthy and safe*
✅ * Seismic and corrosion-resistant* 🏗️ * Suitable for various types of buildings*
